Solarix ethernet cable CAT6 FTP LSOH 500m reel
Planned Delivery Date by Courier to you 08-01-2025
Product description
The installation cable category 6 labeled SXKD-6-FTP-LSOH is a high quality cable for horizontal distribution of structured cabling, which easily meets and also exceeds the requirements specified in the international standards ANSI/TIA/EIA 568, ISO/IEC 11801 and EN 50173, including all the latest additions to category 6 Cables. Installation cables Solarix-category 5E are designed for horizontal distribution and are available in shielded and unshielded versions with different types of shells - ie. PVC, LSOH or UV stable PE. The conductors of these cables are made of high quality copper wire size AWG 23. The individual pairs are separated by a plastic cross. Like other cables, also cable SXKD-6-FTP-LSOH is labeled each one meter in the range of 0-500 m. The cable is supplied on spool, which contains all the necessary product information, including barcodes, production batch, description and main technical parameters (eg. NVP in the form of a QR code).
LSOH installation cables Solarix meet the following standards:
- The acidity of fumes
- IEC 60754-2: Test on gases evolved during combustion of electric cables - Part 2: Determination of degree of acidity of gases evolved during the combustion of materials taken from electric cables by measuring pH and conductivity
- CSN EN 50267-2-2: Common test methods for cables under fire conditions - Tests on gases evolved during combustion of materials from cables - Part 2-2: Procedures - Determination of degree of acidity of gases for materials by measuring pH and conductivity
- CSN EN 50267-2-3: Common test methods for cables under fire conditions - Tests on gases evolved during combustion of materials from cables - Part 2-3: Procedures - Determination of degree of acidity of gases for cables by determination of the weighted average of pH and conductivity
- Smoke Density
- IEC 61034-2: Measurement of smoke density of cables burning under Defined conditions-Part 2: Test procedure and requirements
- CSN EN 61034-2: Measurement of smoke density of cables burning under Defined conditions-Part 2: Test procedure and requirements (this standard has replaced CSN EN 50268-2)
- Non flammability/flame spread of cable with a single insulated
- IEC 60332-1-2: Tests on electric and optical fiber cables under fire conditions-Part 1-2: Test for vertical flame propagation for a single insulated wire or cable-Procedure for 1 kW pre-mixed flame
- CSN EN 60332-1-2: Tests on electric and optical fiber cables under fire conditions-Part 1-2: Test for vertical flame propagation for a single insulated wire or cable-Procedure for 1 kW pre-mixed flame (this standard has replaced CSN EN 50265-2-1)
