Ubiquiti UniFi AP AC Mesh, UAP-AC-M

Ubiquiti UniFi AP AC Mesh, UAP-AC-M
Your price incl. VAT (20.0%)
183.58 BGN
✅ In Stock 90+ Бр.
Delivery Planned Delivery Date by Courier to you 29-05-2024
Ubiquiti Networks
Manufacturer
Product number
UAP-AC-M
Product Code
RL015.534
Warranty
24 months

Product description

UAP-AC-M is wireless accesspoint 2x2 MIMO with modulation speed up to 300 Mbps for 2.4GHz band (802.11b/g/n) and up to 866 Mbps for 5GHz band (802.11a/n/ac). The UniFi AC Mesh AP is designed to discreetly integrate into any environment and can be used indoors or outdoors. Device is compatible with 802.3af PoE Alternative A and 24V passive PoE. You can power it with an 802.3af alternative A compatible switch, EdgePoint™ EP-R6, UniFi PoE Switch, or the included Gigabit PoEadapter. Use the included omni antennas, or use the included fast-mount adapter to install the AP on an optional connectorized antenna for expanded range coverage and customized pattern shaping.

The UniFi AC Mesh AP can be mounted on a wall, pole, or fast-mount of a Ubiquiti high.gain antenna. (All accessories are included.)

Unit central management

UniFi APs doesn't have own web GUI and you manage them via UniFi Controller, which you can download on UBNT websites here: http://www.ubnt.com. Or you can manage UAP devices using UniFi Cloud Key which has UniFi Controller preinstalled. Additional benefit is fact that UniFi Controller software is free of costs and includes advanced functions without limitations.

UAP-AC-M

Main advantages UniFi Mesh product line

  • Plug & Play Mesh technology (wireless multi-hops)
  • Up to 8 SSID
  • Detailed statistisc of traffic
  • Guest network
  • Voucher system
  • Load balance between units
  • Speed limits for each SSID

Package contains

  • Device
  • PoE adapter
  • Power cord
  • Holder
  • Rocket-kit adapter
  • Screws
  • (2) Antennas

Download

https://download.discomp.cz/ubiquiti/datasheets/UniFi_AC_Mesh_DS.pdf
Download Datasheet
https://download.discomp.cz/ubiquiti/other/Certificate_WFA96828.pdf
Download WFA certificate
https://download.discomp.cz/Ubiquiti/Other/MTBF_and_Support_Letter_UAP_(5.16.2019).pdf
Download MTBF Reliability Prediction
https://download.discomp.cz/Ubiquiti/QSG/UniFi_AP-AC-M_QSG.pdf
Download Quick Start Guide

Technical parameters

LAN ports
Power over Ethernet
24V DC, 802.3af, 44 .. 57V DC
Operating mode
Access Point
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11ac, 802.11b/g, 802.11n, 802.11a
Transmission speed - 5GHz [Mb/s]
866
Transmission speed - 2.4GHz [Mb/s]
300
Tx power 2.4GHz [dBm]
20
Tx power 5GHz [dBm]
20
Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Type of antenna
Detachable
Detachable antennas
2
RF connectors
(2) RSMA female
Purpose
Outdoor
Roaming
Yes
Antenna gain [dBi]
4
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
8,5
Buttons
Reset
Operating temperature [°C]
-30 up to 70
Weight [g]
152
Width [mm]
46
Height [mm]
353
Depth [mm]
34
IPv6 support
Transparent (bridge mode)
Default IP address
Dynamic from DHCP
Default login and password
ubnt / ubnt
