Ubiquiti UniFi AP AC High Density, 5-Pack, PoE Not Included - Bazar

Ubiquiti UniFi AP AC High Density, 5-Pack, PoE Not Included - Bazar
used
-12%
Your price incl. VAT (20.0%)
2,620.84 BGN
✅ In Stock < 10 Бр.
Delivery Planned Delivery Date by Courier to you 13-11-2024
Ubiquiti Networks
Manufacturer
Product number
B-UAP-AC-HD-5
Product Code
RL024.374
Warranty
6 months

Product description

The product is fully functional and used at the exhibition. It may not contain complete accessories or original packaging.

Ubiquiti UniFi AC HD is 802.11ac UAP device. It is 4x4 MU-MIMO 2,4GHz and 5GHz Acess point with modulation speed up to 1722+800Mbps supporting 802.11/a/b/g/n/ac/ac-wave2. This UAP is designed for example offices, hotels, warehouses and thanks to high performance is suitable for places with high quantity of connected devices. UAP-AC-HD has two antenas for 2,4GHz band (4dBi) and two antennas for 5GHz band (3dBi) for range up to 122 meters. It full supports roaming for transmission of associated clients between APs. Device features 1x USB 3C port and 2x Gbit LAN - one of them supports 48V (44 - 57V) POE (passive and active 802.3at)

Main MU-MIMO advantages

Thanks to MU-MIMO (Multiple-User - Multiple-In - Multiple-Out) technology UAP AC-HD is able to communicate with several devices at the same time:

  • 4 clients 1x1
  • 2 clients 2x2
  • 1 client 2x2 + 2 clients 1x1
  • 1 client 3x3 + 1 client 1x1

Unit central management

UniFi APs doesn't have own web GUI and you manage them via UniFi Controller, which you can download on UBNT websites here: http://www.ubnt.com. Or you can manage UAP devices using UniFi Cloud Key which has UniFi Controller preinstalled. Additional benefit is fact that UniFi Controller software is free of costs and includes advanced functions without limitations.

UAP-AC-HD

General advantages of UniFi products

  • Zero Handoff Roaming
  • Wireless uplink
  • Up to 8 SSID
  • Detailed traffic stats
  • Guest network
  • Load balance
  • Speed limitaions for each SSID

Package contains

  • (5) Device
  • (5) Ceiling attach kit
  • (5) Screws

Download

https://dl.ubnt.com/datasheets/unifi/UniFi_UAP-AC-HD_DS.pdf
Download Datasheet
https://dl.ubnt.com/guides/UniFi/UniFi_UAP-AC-HD_QSG.pdf
Download Quick Guide

Technical parameters

LAN ports
Power over Ethernet
802.3at, 48V DC
Operating mode
Access Point
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ac - wave2
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
1733
Transmission speed - 2.4GHz [Mb/s]
800
Tx power 2.4GHz [dBm]
25
Tx power 5GHz [dBm]
25
Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) 802.1w/PMF
2.4GHz MIMO
4 x 4
5GHz MIMO
4 x 4
Type of antenna
Built-in
Internal antennas
4
Purpose
Indoor
Roaming
Yes
Antenna gain [dBi]
3, 4
LAN ports
2
LAN speed
(2) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
17
Buttons
Reset
Operating temperature [°C]
-10 up to 70
Weight [g]
700
Width [mm]
220
Height [mm]
48
Depth [mm]
220
IPv6 support
Transparent (bridge mode)
Default IP address
Dynamic from DHCP
Default login and password
ubnt / ubnt
