Teltonika TRB143 M-BUS Gateway
Your price incl. VAT (20.0%)
179.98 EUR / 352.00 BGN
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 11-02-2026
Product description
The TRB143 industrial gateway was designed with an integrated M-Bus interface specifically for telemetry and utility-monitoring applications. It features cellular and wired connectivity, one Gigabit Ethernet port, and a pair of digital Inputs/Outputs, making it applicable to a variety of environment-monitoring scenarios.
Key features
- M-BUS INTERFACE: Supporting up to 250 client devices
- CONNECTIVITY: 4G/LTE (Cat 4), 3G, 2G
- DURABILITY: Rugged aluminum housing
- COMPACT: Simple integration
Package contents
- Device
- 18 W PSU
- Mobile antenna (magnetic mount, SMA male, 3 m cable)
- Hex key
- LAN cable
- QSG (Quick Start Guide)
Download
Technical parameters
LAN ports
RF connectors
(1) SMA female
Power type
4-pin automotive
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
Max. power consumption [W]
6
Power via connector/terminal
12 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
145
Width [mm]
75
Height [mm]
25
Depth [mm]
73
CPU
ARM Cortex A7
CPU frequency [MHz]
1300
SIM slot
Yes
SIM slots quantity
1
Internal storage [MB]
512
RAM [MB]
256
