Ubiquiti AirFiber AF-24HD, 2Gbps+ Backhaul, 24GHz (price per piece)
Planned Delivery Date by Courier to you 29-05-2024
Product description
Featuring the world’s best unlicensed-band spectral efficiency at 15.9 bps/Hz, the airFiber®24 HD supports the dense modulation rates, up to 256QAM, that are required for high data rates, up to 2 Gbps.
2 independent antennas
airFiber features a dual-independent, 2x2 MIMO, high-gain reflector antenna system. Separate yet integrated transmit ( TX) and receive (RX) antennas help extend link budgets by eliminating the extra RF losses caused by the switches or duplexers required in systems with common TX/RX antennas.
FDD and HDD
Conventional wireless standards impose a latency by having to receive a packet before a packet is transmitted. airFiber can transmit data synchronously without any wait time. airFiber features traditional TDD and FDD modes of operation in addition to the proprietary Hybrid Division Duplexing (HDD) mode, which provides a breakthrough in range and spectral efficiency performance.
Based on the ranging algorithm built into the air protocol, the airFiber radios use patent-pending HDD technology to calculate the propagation delay and know when each radio can transmit and receive, so they send packets in precise synchronization. Packet transmission latency is virtually eliminated.
2 Ethernet ports
For seamless monitoring and settings is used in the unit 2 Ethernet ports, one of whom is designed only for management 2nd one for data and management.
Package contains
- Device
- PoE power adapter
- Power cord
- Holder
