Ubiquiti UCG-Ultra, UniFi Cloud Gateway Ultra

Product description

UCG-Ultra is a all-round device from the UniFi Cloud Gateway series. The router has (1) WAN 1/2.5Gbps port and (4) LAN 1Gbps ports (1 with LAN/WAN configuration option). The compact and powerful device thus supports the multi-WAN function, including the option of load balancing, and also supports IDS/IPS. The router has implemented support for various types of VPN, including site-to-site VPN.

Using the integrated UniFi Network App you can manage up to 30+ UniFi devices and serve up to 300+ connected client devices. There is a 0.96-inch status display. Power is provided via the USB-C connector, the power adapter is included in the package.

Key features

• 1Gbps routing with IDS/IPS support
• Integrated UniFi Network App
• Multi-WAN + load balancing
• 0.96" LCM display
• USB-C power

Package contents

• Device
• Patch cable
• USB-C power adapter (5V/3A)

Download

https://dl.ui.com/qig/ucg-ultra/#index

Quick installation guide

https://techspecs.ui.com/unifi/unifi-cloud-gateways/ucg-ultra#datasheet

Datasheet
