RF elements Omnidirectional indoor dual antenna for SBX InSpot MMCX


Your price incl. VAT (20.0%)
3.64 BGN
✅ In Stock 90+ Бр.

Product description
This Compact Indoor Omni-Directional Dual Antenna is designed to be used with MikroTik RouterBoard RB912/RB711 when installed inside of StationBox® InSpot.Direct connection to MMCX port of integrated radio eliminates pigtails, saves cost and decreases RF losses. Installation is super quick and easy.

- 2dBi (2,4GHz)
- 3dBi (5GHz)
Download
Technical parameters
LAN ports
MIMO, SISO
1 x 1
VSWR
< 2,0
Wireless frequency
2.4 + 5 GHz (dual band)
Elevation beam width (-6dB) [°]
13
Azimuth beam width (-6dB) [°]
360
Antenna type
Omnidirectional
RF connectors
(1) MMCX
Purpose
Indoor
Antenna gain [dBi]
3, 2
Material
UV stabilized plastic
Weight [kg]
0,1
Width [mm]
8
Height [mm]
8,9
Depth [mm]
8
