Product description
The GWN7800 series are Layer 2+ managed network switches that allow small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable.
Key features
- 8 Gigabit Ethernet ports and 2 Gigabit SFP ports
- Supports deployment in IPv6 and IPv4 networks
- Provides quaternary binding of IP, MAC, VLAN, ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Local Web UI to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform
- Built-in QoS allows for prioritization of network traffic
Download
Technical parameters
LAN ports
Design
On the wall, Desktop
Switchning capacity [Gbps]
20
MAC address table
8000
Packet forwarding rate [Mpps]
14,9
Web management
Yes
Management
Web management, SSH, Telnet, Cloud (GDMS)
Features
VLAN, QoS, DHCP snooping, L2+
Power type
Mains power (230V)
Fans
No
LAN ports
8
LAN speed
(8) 10/100/1000Mbps
Max. LAN ports speed
1G
SFP cages
2
Optical interfaces
(2) 1000Mbps
Serial port
RJ45
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
1,8
Width [mm]
300
Height [mm]
44
Depth [mm]
175
Default IP address
192.168.0.254
Default login and password
admin / (preset password, see label/engraving)
