Grandstream GWN7813P Layer 3 Managed Network PoE Switch, 24 ports / 4 SFP+
Your price incl. VAT (20.0%)
793.58 BGN
✅ Availability in an external Partner
Planned Delivery Date by Courier to you 01-01-2025
301.48 BGN excl. VAT
443.64 BGN excl. VAT
1342.89 BGN excl. VAT
482.80 BGN excl. VAT
12.66 BGN excl. VAT
19.89 BGN excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDMML-S+2733-10
26.60 BGN excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDMML-S+3327-10
26.60 BGN excl. VAT
Product description
The GWN7810 series are Layer 3 managed network switches that allow enterprises to build scalable, secure, and high-performance business networks that are fully manageable.
Key features
- 8/16/24 Gigabit Ethernet ports and 2/4 10Gigabit SFP+ ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models, Ports 1-8 on the GWN7813P support PoE++
- Supports deployment in IPv6 and IPv4 networks
- ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Embedded controller to manage switch; GWN Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform
- Built-in QoS allows for prioritization of network traffic
Download
Technical parameters
LAN ports
Design
Rackmount, Desktop, On the wall
Switchning capacity [Gbps]
128
Packet forwarding rate [Mpps]
95,2
Web management
Yes
Management
Cloud (GDMS), SSH, Telnet, Web management
Features
DHCP snooping, L3, QoS, VLAN
Power type
Mains power (230V)
Fans
Yes
LAN ports
24
LAN speed
(24) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP+ cages
4
Optical interfaces
(4) 10Gbps
PoE-Out standards
802.3af, 802.3at, 802.3bt
Redundant power supply
Yes
PoE Out ports
24
PoE budget [W]
360
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
4,7
Width [mm]
440
Height [mm]
44
Depth [mm]
300
Default IP address
192.168.0.254
Default login and password
admin / (preset password, see label/engraving)
