Teltonika RUTM52 Dual 5G Router
Your price incl. VAT (20.0%)
1,979.46 BGN
❌ The item is not available. There is no option to order.
No confirmed delivery date
Product description
The RUTM52 is a future-proof 5G router designed for mission-critical applications, featuring dual 5G modems, multi-WAN capabilities, and 4G LTE Cat 20 fallback. With dual SIM slots, eSIM support, and compatibility with SA and NSA 5G architectures, it ensures high-speed, uninterrupted connectivity today and years ahead. Load balancing, Wi-Fi 5, and five Gigabit Ethernet ports enhance performance, while RutOS with industrial protocols and various VPNs make it versatile for complex setups. Compatible with RMS, the RUTM52 is ideal for secure and efficient remote management.
Key features
- DUAL 5G MODEM: Up to double cellular speeds and always-on connection
- DUAL SIM & eSIM™: With auto failover, backup WAN and other switching scenarios
- SA & NSA: Supports both architectures to leverage the 5G infrastructure
- FUTURE-PROOFING: Backward compatible with 4G (LTE Cat 20)
Package contents
- Device
- 18 W PSU
- 8 x 5G Mobile antennas (magnetic mount, SMA male)
- 2 x Wi-Fi antennas (magnetic mount, RP-SMA male, 1.5 m cable)
- 1 x GNSS antenna (adhesive, SMA male, 3 m cable)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
Download
Technical parameters
LAN ports
Power over Ethernet
9 .. 50V DC
Design
Desktop, DIN rail, On the wall
Supported VPN
GRE, IPSec, L2TP, OpenVPN, PPTP, Tinc, WireGuard, ZeroTier
Operating mode
3G/4G Router, Access Point, AP Router, Client
Management
SSH, Teltonika RMS, Web management
Wireless frequency
2.4 + 5 GHz (dual band), 3G (GSM), 4G (GSM), 5G (GSM), LTE
WiFi standards
802.11ac - wave2, 802.11b/g, 802.11n
Transmission speed - 5GHz [Mb/s]
866
Transmission speed - 2.4GHz [Mb/s]
300
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Detachable
Detachable antennas
11
RF connectors
(1) SMA female, (2) RSMA female, (8) SMA female
Integrated 4G/LTE radio part
Yes
Power type
DC connector, PoE
4G/LTE bands support
(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (32) 1500 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz
5G bands support
(n1) 2100 MHz, (n20) 800 MHz, (n28) 700 MHz, (n3) 1800 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n8) 900 MHz
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
4
LAN speed
(4) 10/100/1000Mbps + (1) 10/100/1000 WAN
Max. power consumption [W]
13
Power via connector/terminal
9 .. 50V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
560
Width [mm]
132
Height [mm]
44
Depth [mm]
95
CPU
MediaTek, Dual-Core, 880 MHz, MIPS1004Kc
CPU frequency [MHz]
880
SIM slot
Yes
SIM slots quantity
2
IPv6 support
Yes
Default IP address
192.168.1.1
Internal storage [MB]
256
RAM [MB]
256
Default login and password
admin / (preset password, see label/engraving)
GPS modul
Yes
