Ubiquiti UMR-Ultra LTE router

Design

DIN rail, On the wall

Operating mode

3G/4G Router

WiFi standards

802.11b/g, 802.11n

Transmission speed - 2.4GHz [Mb/s]

150

Tx power 2.4GHz [dBm]

17

Type of antenna

Detachable

Detachable antennas

3

Integrated 4G/LTE radio part

Yes

4G/LTE bands support

(12) 700 MHz, (13) 700 MHz, (2) 1900 MHz, (25) 1900 MHz, (26) 850 MHz, (4) 1700 MHz, (5) 850 MHz, (66) 1700 MHz, (71) 600 MHz, (14) 700 MHz

LAN ports

2

LAN speed

(2) 10/100Mbps

Max. power consumption [W]

6

Power via connector/terminal

9 .. 30V DC

Buttons

Reset

Operating temperature [°C]

-30 up to 70

Width [mm]

82

Height [mm]

194

Depth [mm]

26

SIM slot

Yes

SIM slots quantity

1
