Teltonika RUTM54 Telit 5G Router
Your price incl. VAT (20.0%)
1,172.45 BGN
Ordered for stock
Planned Delivery Date by Courier to you 12-02-2025
Product description
The RUTM54 is a high-performance, dual-SIM and eSIM 5G router, ideal for data-intensive applications that demand reliable, high-speed connectivity. With a European Telit 5G modem, the RUTM54 delivers exceptional global connectivity and consistent performance. Its 5 Gigabit Ethernet ports and dual-band Wi-Fi provide robust redundancy, while auto-failover ensures uninterrupted service. With backward compatibility to 4G and multiple interface options, the RUTM54 is designed for seamless expandability and future upgrades.
Key features
- 5G - Ultra-high cellular speeds of up to 3.4 Gbps
- DUAL SIM & eSIM™ - With auto failover, backup WAN and other switching scenarios
- SA & NSA - Supports both architectures to leverage the 5G infrastructure
- TELIT MODEM - European made module inside
Package contents
- Device
- 18 W PSU
- 4 x Mobile antennas (swivel, SMA male)
- 2 x Wi-Fi antennas (magnetic mount, RP-SMA male, 1.5 m cable)
- 1 x GNSS antenna (adhesive, SMA male, 3 m cable)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
Download
Technical parameters
LAN ports
Design
On the wall, Desktop, DIN rail
Supported VPN
PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE, Tinc
Power over Ethernet
9 .. 50V DC
Operating mode
Client, AP Router, Access Point, Cellular router
Management
Web management, SSH, Teltonika RMS
Wireless frequency
2.4 + 5 GHz (dual band), LTE, 3G (GSM), 4G (GSM), 5G (GSM)
WiFi standards
802.11n, 802.11ac, 802.11b/g
Transmission speed - 2.4GHz [Mb/s]
300
Transmission speed - 5GHz [Mb/s]
866
Tx power 5GHz [dBm]
28
Tx power 2.4GHz [dBm]
20
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Detachable
Detachable antennas
7
RF connectors
(2) RSMA female, (1) SMA female, (4) SMA female
Integrated 4G/LTE radio part
Yes
Power type
DC connector, PoE
4G/LTE bands support
(1) 2100 MHz, (2) 1900 MHz, (3) 1800 MHz, (4) 1700 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (5) 850 MHz, (12) 700 MHz, (17) 700 MHz, (25) 1900 MHz, (26) 850 MHz, (28) 700 MHz, (13) 700 MHz, (18) 850 MHz, (19) 850 MHz, (32) 1500 MHz, (14) 700 MHz
5G bands support
(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n75) 1500 MHz, (n76) 1500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n79) 4700 MHz, (n66) 1700 MHz
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
5
LAN speed
(4) 10/100/1000Mbps + (1) 10/100/1000Mbps WAN
Max. power consumption [W]
14
Power via connector/terminal
9 .. 50V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
530
Height [mm]
44
Depth [mm]
95
Width [mm]
132
CPU
MediaTek, Dual-Core, 880 MHz, MIPS1004Kc
CPU frequency [MHz]
880
SIM slot
Yes
SIM slots quantity
2
USB
Yes
IPv6 support
Yes
Default IP address
192.168.1.1
Internal storage [MB]
256
RAM [MB]
256
Default login and password
admin / (preset password, see label/engraving)
GPS modul
Yes
