Grandstream GWN7700MP Unmanaged Network Switch - 1x SFP+

Grandstream GWN7700MP Unmanaged Network Switch - 1x SFP+
Your price incl. VAT (20.0%)
135.35 BGN / 69.20 EUR
✅ Availability in an external Partner
Delivery Planned Delivery Date by Courier to you 20-08-2025
Manufacturer
Product number
GWN7700MP
Product Code
RL029.115
Warranty
36 months

Product description

The GWN7700M series are 5 & 8 port unmanaged multi-Gigabit network switches that provide high-speed network connectivity up to 2.5Gbps to home offices and small-to-medium businesses. These 6 and 9-port multi-Gigabit switches support fast Ethernet, 1-Gigabit and 2.5-Gigabit network speeds while including 1 SFP+ Gigabit fiber port that provides 1-Gigabit or 10-Gigabit high-speed uplink connectivity to your network. The GWN7700M, GWN7700MP, and GWN77001M require no configuration or installation, are desktop and wall-mountable, and provide auto MDI/MDIX to eliminate the need for crossover cables.

Grandstream GWN7700MP

Key features

  • 5x Multi-Gigabit Copper Ports provide 100/1000/2500Mbps connectivity
  • One SFP+ Fiber Port with 1 Gigabit or 10-Gigabit connectivity
  • LED Indicators; Per port: Link/Activity/Speed Per device: Power
  • Auto MDI/MDIX crossover for all ports
  • Whisper Quiet: fanless
  • Broadcast/Multicast/Unicat Storm Control (fixed to 100Mbps) to monitor traffic levels
  • Green technology reduces power consumption
  • QoS - Supports Default Strict Priority when present

Package contents

  • Device
  • Power Adapter
  • Quick Installation Guide

Download

https://download.discomp.cz/Grandstream/Datasheets/Datasheet_GWN7700M_GWN7700MP_GWN7701M_English.pdf
Download Datasheet
https://download.discomp.cz/Grandstream/QIG/GWN770xM_QIG_ML.pdf
Download Quick Installation Guide

Technical parameters

LAN ports
Design
On the wall, Desktop
Switchning capacity [Gbps]
45
MAC address table
4000
Jumbo frame [Bytes]
9000
Features
QoS
Power type
DC connector
Fans
No
LAN ports
5
LAN speed
(5) 100M/1G/2.5Gbps
Max. LAN ports speed
2.5G
PoE type
PoE-Out (only)
SFP+ cages
1 (podpora 1G/10G)
Optical interfaces
(1) 1/10Gbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
4
PoE budget [W]
57
Max. power consumption [W]
7,2
Chassis design
Metal
Power via connector/terminal
53,5V/1,22A
Operating temperature [°C]
0 up to 40
Weight [g]
310
Width [mm]
145
Height [mm]
27
Depth [mm]
80
