Grandstream GWN7661 Wi-Fi 6 In-Wall Access Point
Your price incl. VAT (20.0%)
198.74 BGN / 101.62 EUR
✅ Availability in an external Partner
Planned Delivery Date by Courier to you 29-10-2025
Product description
The GWN7661 is an in-wall 802.11ax Wi-Fi 6 access point that provides three Gigabit network ports to provide IP phones, computers and similar devices with Ethernet while also providing and uplink Gigabit network port with PoE/PoE+.
Key features
- Up to 1.77 Gbps wireless throughput and 4x Gigabit wireline ports
- Dual-band 2×2 MU-MIMO with DL/UL OFDMA technology
- Supports up to 500+ concurrent Wi-Fi client devices
- Self power adaptation upon auto detection of PoE or PoE+
- Advanced QoS to ensure real-time performance of low-latency applications
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
- Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
Package contents
- Device
- Mounting Kits
- Quick Installation Guide
Download
Technical parameters
LAN ports
Power over Ethernet
802.3af, 802.3at
WAN speed
(1) 10/100/1000Mbps
Frequency range [MHz]
5180 - 5825
Operating mode
Access Point
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
1201
Transmission speed - 2.4GHz [Mb/s]
574
Tx power 2.4GHz [dBm]
24
Tx power 5GHz [dBm]
27
Security
WEP, WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Built-in
Internal antennas
4
Purpose
Indoor
Antenna gain [dBi]
3,5, 5,4
PoE Input ports
1
LAN ports
4
LAN speed
(3) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-Out + PoE-In
PoE Out ports
2
PoE budget [W]
12
Max. power consumption [W]
25
Buttons
Reset
Operating temperature [°C]
-10 up to 50
Width [mm]
86
Height [mm]
135
Depth [mm]
39
IPv6 support
Yes
