MikroTik RouterBOARD E62iUGS-2axD5axT, hAP ax S
Your price incl. VAT (20.0%)
134.53 BGN / 68.78 EUR
Ordered for stock
Planned Delivery Date by Courier to you 31-12-2025
9.04 BGN / 4.62 EUR excl. VAT
9.37 BGN / 4.79 EUR excl. VAT
MaxLink 1.25G SFP optical module, WDM(BiDi), SM, Tx 1310/Rx1550nm, 20KM, 1x LC connector, DDMML-S3155-20
8.78 BGN / 4.49 EUR excl. VAT
9.21 BGN / 4.71 EUR excl. VAT
MaxLink 1.25G SFP optical module, WDM(BiDi), SM, Tx 1550/Rx1310nm, 20km, 1x LC connector, DDMML-S5531-20
11.97 BGN / 6.12 EUR excl. VAT
25.29 BGN / 12.93 EUR excl. VAT
Product description
The MikroTik hAP ax S is a high-performance dual-band Wi-Fi 6 routerboard offering real-world throughput of around 800-900Mbps, enabled by its triple-chain 5GHz radio. The device features (5) Gbit ports (1x PoE-In, 1x PoE-Out), (1) 2.5G SFP slot and (1) USB port. Thanks to its high performance and low latency, it is also an excellent AP for VR streaming for PCVR headsets.
Key features
- (5) Gbit ports (1x passive PoE-In, 1x passive PoE-Out) and (1) 2.5G SFP slot
- Total wireless throughput up to 2.37Gbps - 574Mbps at 2.4GHz (2x2) and 1800Mbps at 5GHz (3x3)
- RouterOS v7 L4 provides full control - no subscriptions and no locked features
- Passive cooling - silent operation, suitable for office environments
- Powering - passive PoE (18-28VDC), or DC connector (12-28VDC)
Package contents
- Device
- Power adapter 24V/1,5A
Download
Technical parameters
LAN ports
Design
On the wall, Desktop
Sensitivity [dBm]
-100
Power over Ethernet
18 .. 28V DC
Operating mode
AP Router
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax
Transmission speed - 5GHz [Mb/s]
1800
Transmission speed - 2.4GHz [Mb/s]
574
Tx power 2.4GHz [dBm]
24
Tx power 5GHz [dBm]
23
2.4GHz MIMO
2 x 2
5GHz MIMO
3 x 3
Type of antenna
Built-in
Internal antennas
5
Purpose
Indoor
Antenna gain [dBi]
5,5, 8
Power type
DC connector, PoE
Operating system
RouterOS v7 - L4
Fans
No
LAN ports
5
LAN speed
(5) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-Out + PoE-In
SFP cages
1 (podpora 1G/2.5G)
Optical interfaces
(1) 1G/2.5Gbps
PoE Out ports
1
Max. power consumption [W]
34
Chassis design
Plastic
Power via connector/terminal
12 .. 28V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 70
Depth [mm]
127
Height [mm]
36
Width [mm]
156
CPU
EN7562CT
CPU frequency [MHz]
950
CPU cores
2
USB
Yes
Internal storage [MB]
128
Default IP address
192.168.88.1
RAM [MB]
512
Default login and password
admin / (preset password, see label/engraving)
