Wi-Tek WI-PS402-UPS-I Solar 2.5G PoE Injector
Your price incl. VAT (20.0%)
112.38 EUR / 219.80 BGN
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 15-04-2026
Product description
Wi-Tek WI-PS402-UPS-I is a solar powered PoE injector with UPS functionality featuring (2) 2.5G PoE++ ports. The integrated MPPT controller optimizes solar panel performance by monitoring voltage in real time and ensuring efficient battery charging. It manages power flow between solar panels, the battery, and connected loads, allowing the system to operate on solar energy during the day and on battery power at night. The switch consumes <5W (without PoE load and DC output).
The injector supports both solar and DC power, making it suitable for hybrid or backup systems (solar + mains power). However, the solar input cannot power the injector independently without a connected battery. The maximum charging current is 15A.
Key features
- (2) 2.5G PoE++ ports
- Cloud management via Wi-Tek Cloud - provides efficient, simple, and secure remote device management *(requires connection through the WI-IOT100 cloud controller)
- Configurable relay output for remote switching
- 12/24 VDC output for external power supply
- Digital input (DI dry contact) for passive status detection
- Side DIP switch sets the battery type (see table in the quick installation guide)
| Battery type | PoE Budget | Port 1 | Port 2 |
|---|---|---|---|
| 12V | 120W | PoE++ 802.3bt (up to 90W) | PoE+ 802.3af/at (up to 30W) |
| 24V | 180W | PoE++ 802.3bt (up to 90W) | PoE++ 802.3bt (up to 90W) |
Package contents
- Device
- Screwdriver
- Quick Installation Guide
Download
Technical parameters
LAN ports
Design
On the wall, Desktop, DIN rail
Pin powering
1,2,4,5 (+), 3,6,7,8 (-)
Output Power / 1port [W]
90
Web management
Yes
Management
Web management
Power type
Battery, DC terminal
Charging function
Yes
Fans
No
LED indication
Yes
LAN speed
(2) 100M/1G/2.5Gbps
Max. LAN ports speed
2.5G
Gigabit LAN
Yes
PoE type
PoE-Out (only)
RJ45 ports 2.5G
2
PoE-Out standards
802.3af, 802.3at, 802.3bt
PoE Out ports
2
PoE budget [W]
180
Chassis design
Metal
Operating temperature [°C]
-40 up to 75
Weight [g]
880
Width [mm]
158
Height [mm]
44
Depth [mm]
115
Other features
RS485
