Max. WAN speed

100M

Power over Ethernet

16 .. 57V DC, 802.3af

Design

Industry

Operating mode

AP Router, Cellular router

Wireless frequency

2.4 GHz, 2G (GSM), 3G (GSM), LTE, GNSS

WiFi standards

802.11b/g, 802.11n

Transmission speed - 2.4GHz [Mb/s]

150

Security

WPA, WPA2, WPA3, OWE

2.4GHz MIMO

1 x 1 SISO

Type of antenna

Detachable

Detachable antennas

4

RF connectors

(3) SMA female, (1) RP-SMA female

Integrated 4G/LTE radio part

Yes

4G/LTE bands support

(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz

Power type

DC terminal, PoE

Operating system

RutOS (OpenWrt based Linux OS)

LAN speed

(2) 10/100Mbps

LAN ports 100M

2

PoE type

PoE-In (only)

Max. power consumption [W]

3,5

Serial port

RS-232

Power via connector/terminal

9 .. 57V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

140

Depth [mm]

83

Width [mm]

83

Height [mm]

25

CPU frequency [MHz]

580

SIM slots quantity

2

SIM slot

Yes

IPv6 support

Yes

Internal storage [MB]

32

Default IP address

192.168.1.1

RAM [MB]

128

Default login and password

admin / (preset password, see label/engraving)

GPS modul

Yes
