Category
Your price incl. VAT (20.0%)
0.00 EUR / 0.00 BGN
You have a choice of 2 variants
Technical parameters
LAN ports
Jumbo frame [Bytes]
9216
Design
Industry, DIN rail
MAC address table
2000
Power type
DC connector
LAN speed
(8) 10/100Mbps
Max. LAN ports speed
100M
PoE type
PoE-Out (only)
RJ45 ports 100M
8
PoE-Out standards
802.3af, 802.3at
PoE Out ports
8
PoE budget [W]
240
Max. power consumption [W]
246
Chassis design
Metal
Power via connector/terminal
7 .. 57V DC
Operating temperature [°C]
-40 up to 75
Weight [g]
280
Depth [mm]
75
Width [mm]
113
Height [mm]
41
