Teltonika TRB145 LTE RS485 Gateway
Your price incl. VAT (20.0%)
213.31 BGN
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 01-01-2025
Product description
Industrial GSM/GPRS Gateway Board TRB145 is equipped with an RS485 Interface, Digital Inputs/Outputs and a microUSB port.
TRB145 compact design makes this Gateway perfect for an application where a sole gadget must be remotely controlled over RS485 interface.
The gateway is engineered to be used in Industrial applications, therefore, it has a wide range of software features such as SMS control, Firewall, OpenVPN, IPsec, RMS and FOTA support.
Package contents
- Device
- LTE antenna with cable
- Power adapter (EU)
- USB cable
Download
Technical parameters
LAN ports
RF connectors
(1) SMA female
Power type
DC connector
Operating system
RutOS (OpenWrt based Linux OS)
Max. power consumption [W]
5
Serial port
RS-485
Power via connector/terminal
9 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
150
Width [mm]
60
Height [mm]
18
Depth [mm]
70
CPU
ARM Cortex A7
CPU frequency [MHz]
1200
SIM slot
Yes
SIM slots quantity
1
USB
Yes
Internal storage [MB]
512
RAM [MB]
128
