https://download.discomp.cz/Teltonika/Datasheets/5G%20COMBO%20MOBILE-GNSS%20SMA%20ANTENNA%20v-1.0%20PR1KCN40.pdf
Download Datasheet

Technical parameters

LAN ports
RF cable length [m]
3
Protection class
IP67
Wireless frequency
5G (GSM), GNSS
RF connectors
(5) SMA male
Purpose
Outdoor
Antenna gain [dBi]
2, 4
Operating temperature [°C]
-40 up to 80
Weight [g]
450
Width [mm]
224
Height [mm]
36
Depth [mm]
100
