Ubiquiti UniFi AP U7-Outdoor

Ubiquiti UniFi AP U7-Outdoor
Your price incl. VAT (20.0%)
421.72 BGN
Ordered for stock
Delivery No confirmed delivery date
Ubiquiti
Manufacturer
Product number
U7-Outdoor
Product Code
RL027.570
Warranty
24 months

Product description

Ubiquiti U7 Outdoor is a new outdoor dual-band unit supporting Wi-Fi 7. It operates in the 2.4 GHz band at a speed of 688 Mb/s and in the 5 GHz band at a speed of 4.3 Gb/s. Two external antennas can be added to the unit using RP-SMA connectors on the top. For network connection, a LAN port with a speed of up to 2.5 Gb/s is available. The access point is powered via PoE+.

The access point offers wide mounting options for the wall and pole, and the mounting accessories are included in the package.

Centralized Unit Management

To manage the device, it is necessary to download the original software called UniFi Network Controller from the official website, which allows managing the entire network. An undeniable advantage of the UniFi Controller is that it is completely free without any limitations! This centralized management allows uploading maps and setting both basic parameters and advanced functions, such as SSID, guest account, splash page, traffic statistics, and a list and status of associated clients, easily and quickly.

U6-LR

Package Contents

  • Device
  • Wall and pole mounts
  • Drilling template
  • Cable tie
  • Mounting kit

Download

https://dl.ui.com/qig/u7-outdoor/#index
Download Quick Guide
https://techspecs.ui.com/unifi/wifi/u7-outdoor
Download Datasheet

Technical parameters

LAN ports
Power over Ethernet
Yes, 42 .. 57V DC
Protection class
IPX6
Operating mode
Access Point
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11a, 802.11ac, 802.11ax, 802.11b/g, 802.11be, 802.11n
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
4300
Transmission speed - 2.4GHz [Mb/s]
688
Tx power 2.4GHz [dBm]
23
Tx power 5GHz [dBm]
26
Security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Built-in
Internal antennas
3
RF connectors
(2) RP-SMA
Purpose
Outdoor
Antenna gain [dBi]
8, 13
LAN ports
1
LAN speed
(1) 100/1000/2500Mbps
Gigabit LAN
Yes
Max. power consumption [W]
19
Buttons
Reset
Operating temperature [°C]
-30 up to 60
Weight [g]
1200
Width [mm]
170
Height [mm]
208
Depth [mm]
55
IPv6 support
Transparent (bridge mode)
Default IP address
Dynamic from DHCP
Default login and password
ubnt / ubnt
