Ubiquiti UniFi AP U7-Pro-Outdoor

Ubiquiti UniFi AP U7-Pro-Outdoor
Your price incl. VAT (20.0%)
596.05 BGN
Ordered for stock
Delivery No confirmed delivery date
Ubiquiti
Manufacturer
Product number
U7-Pro-Outdoor
Product Code
RL028.893
Warranty
24 months

Product description

The Ubiquiti U7 Pro Outdoor is a new outdoor triple-band unit supporting Wi-Fi 7. It operates in the 2.4 GHz band at speeds of up to 688 Mbps, the 5 GHz band at up to 4.3 Gbps, and the 6 GHz band at up to 5.7 Gbps. The unit features a built-in antenna with a gain of 8-10 dBi and a 90° beamwidth. Additionally, the package includes two external omnidirectional antennas that can be connected via RP-SMA connectors located at the top. For network connectivity, it provides a LAN port supporting speeds of up to 2.5 Gbps. The access point is powered via PoE+ (adapter not included).

The access point offers versatile mounting options for walls, ceilings, or poles, and includes mounting accessories in the package, along with a weatherproof cable gland for outdoor use.

Centralized Unit Management

The device requires downloading the official UniFi Controller software from the official website, which enables centralized network management. A significant advantage of the UniFi Controller is that it is completely free without any limitations! This central management system allows you to upload maps, configure basic parameters such as SSID, guest accounts, splash pages, traffic statistics, and view a list and status of connected clients quickly and easily.

U7-Pro-Outdoor

Benefits of UniFi Solutions

  • Zero Handoff Roaming - seamless transition between access points
  • Wireless uplink (ideal for locations where a data cable cannot be run)
  • Up to 8 SSIDs
  • Detailed traffic statistics
  • Guest network
  • Voucher system
  • Load balancing - maintaining balanced client distribution
  • Bandwidth limiting for each SSID

Package Contents

  • Device
  • Wall, ceiling, and pole mounts
  • Weatherproof cable gland
  • Drilling template
  • Cable tie
  • Mounting kit

Download

https://dl.ui.com/qig/u7-pro-outdoor/#index
Download QIG
https://techspecs.ui.com/unifi/wifi/u7-pro-outdoor-us#datasheet
Download Datasheet

Technical parameters

LAN ports
Power over Ethernet
42 .. 57V DC
Operating mode
Access Point
Wireless frequency
2.4 + 5 + 6 GHz (triple band)
WiFi standards
802.11a, 802.11ac, 802.11ax, 802.11b/g, 802.11be, 802.11n
MU-MIMO
Yes
Hotspot 2.0
Yes
Transmission speed - 5GHz [Mb/s]
4300
Transmission speed - 2.4GHz [Mb/s]
688
Transmission speed - 6GHz [Mb/s]
5700
Tx power 2.4GHz [dBm]
23
Tx power 5GHz [dBm]
26
Tx power 6GHz [dBm]
24
Security
WPA, WPA2, WPA3
Azimuth beam width (-6dB) [°]
90
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
6GHz MIMO
2 x 2
Type of antenna
Detachable, Built-in
Internal antennas
1
Detachable antennas
2
RF connectors
(2) RSMA female
Purpose
Outdoor
Roaming
Yes
Antenna gain [dBi]
10, 11, 6, 8
LAN ports
1
LAN speed
(1) 1G/2.5Gbps
Gigabit LAN
Yes
Max. power consumption [W]
21
Buttons
Reset
Operating temperature [°C]
-30 up to 60
Weight [g]
1200
Width [mm]
170
Height [mm]
208
Depth [mm]
67
IPv6 support
Yes
Default IP address
Dynamic from DHCP, 192.168.1.20
Default login and password
ubnt / ubnt
