Grandstream GWN7801P Pro, Gigabit PoE switch
Your price incl. VAT (20.0%)
159.35 EUR / 311.66 BGN
✅ Availability in an external Partner
Planned Delivery Date by Courier to you 24-06-2026
You have a choice of 7 variants
4.84 EUR / 9.47 BGN excl. VAT
4.65 EUR / 9.09 BGN excl. VAT
MaxLink 1.25G SFP optical module, WDM(BiDi), SM, Tx 1310/Rx1550nm, 20KM, 1x LC connector, DDMML-S3155-20
4.65 EUR / 9.09 BGN excl. VAT
4.79 EUR / 9.37 BGN excl. VAT
MaxLink 1.25G SFP optical module, WDM(BiDi), SM, Tx 1550/Rx1310nm, 20km, 1x LC connector, DDMML-S5531-20
6.36 EUR / 12.44 BGN excl. VAT
Product description
The Grandstream GWN7801P Pro is a managed L2+ switch with a switching capacity of 26Gbps, offering (8) 1G PoE+ ports, a PoE budget of 120W, (2) 2.5G SFP slots and support for management via local web interface, GDMS cloud management and GWN Manager.
Key features
- (8) 1Gbps PoE+ ports, (2) 2.5Gbps SFP slots and (1) RJ45 console port
- 802.3af/at PoE+ with up to 30W/port and a total budget of up to 120W
- Convenient and intelligent management via the web user interface and the cloud
- VLAN, QoS, ARP Inspection, IP Source Guard, DoS protection, port security and DHCP snooping
Package contents
- Device
- Rack mounting kit
- Power cable
Technical parameters
LAN ports
Jumbo frame [Bytes]
12000
Design
Rackmount, Desktop
Packet forwarding rate [Mpps]
19,3
Switchning capacity [Gbps]
26
MAC address table
16000
Web management
Yes
Management
Cloud (GDMS), Web management, SSH, Telnet
Features
L2+, VLAN, QoS, DHCP snooping
Power type
Mains power (230V)
Fans
No
LAN speed
(8) 10/100/1000Mbps
Management LAN
Yes
PoE type
PoE-Out (only)
RJ45 ports 1G
8
SFP cages
2
Optical interfaces
(2) 1G/2.5Gbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
8
PoE budget [W]
120
Max. power consumption [W]
145
Serial port
RJ45
Chassis design
Metal
Buttons
Reset
Operating temperature [°C]
0 up to 45
Depth [mm]
175
Width [mm]
330
Height [mm]
44
Default IP address
192.168.0.254, Dynamic from DHCP
Default login and password
admin / (preset password, see label/engraving)
