Ubiquiti UMR-Ultra LTE router

Ubiquiti UMR-Ultra LTE router
Вашата цена с ДДС (20.0%)
185.22 ЛВ / 94.70 EUR
Поръчан за склад
Delivery Планирана Дата Доставка на Куриер до Вас 03-09-2025
Ubiquiti
Производител
Продуктов номер
UMR-Ultra
Продуктов Код
RL028.719
Гаранция
24 месеца

Описание на продукт

Това е автоматичен превод. Оригиналния текст може да видите тук

UniFi Mobile Router is a compact device with wide power options, two LAN ports, WiFi and LTE Cat4 modem.

One of the pair of gigabit ethernets also supports the PoE-out function. Power options are via a USB-C connector or a 4-pin connector. The router can be mounted directly on the wall with the included bracket or on a DIN rail using an additional intermediate piece, which is also included in the package. You can connect wirelessly at a frequency 2.4GHz with a maximum line speed 150Mbps. The LTE modem reaches category 4, which means speeds up to 150/50Mbps. You connect to the mobile operator's network using your own nanoSIM.

GPS and WiFi antennas are integrated inside the router, LTE antennas are detachable, the SIM slot is hidden under the antennas. The maximum consumption of the device itself is 5.7W.

The device is managed locally via a web interface, and the manufacturer also offers remote management through the UniFi Mobility Manager portal, which is, however, subject to a fee.

Package contains

  • Device
  • DIN rail
  • Wall mount bracket
  • DIN mount bracket
  • (4) Screws and anchors
  • LTE antennas

Свали

https://dl.ui.com/qig/umr-ultra/#index
Свали QSG
https://techspecs.ui.com/unifi/integrations/umr-ultra-us#datasheet
Свали Datasheet

Технически параметри

LAN ports
Design
DIN rail, On the wall
Operating mode
Cellular router
WiFi standards
802.11b/g, 802.11n
Transmission speed - 2.4GHz [Mb/s]
150
Tx power 2.4GHz [dBm]
17
Type of antenna
Detachable
Detachable antennas
3
Integrated 4G/LTE radio part
Yes
4G/LTE bands support
(12) 700 MHz, (13) 700 MHz, (2) 1900 MHz, (25) 1900 MHz, (26) 850 MHz, (4) 1700 MHz, (5) 850 MHz, (66) 1700 MHz, (71) 600 MHz, (14) 700 MHz
LAN ports
2
LAN speed
(2) 10/100Mbps
Max. power consumption [W]
6
Power via connector/terminal
9 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-30 up to 70
Width [mm]
82
Height [mm]
194
Depth [mm]
26
SIM slot
Yes
SIM slots quantity
1
