Teltonika OTD500 - 5G Outdoor Router
Вашата цена с ДДС (20.0%)
852.95 лв
Поръчан за склад
Планирана Дата Доставка на Куриер до Вас 12-02-2025
Описание на продукт
Това е автоматичен превод. Оригиналния текст може да видите тукThe OTD500 is a durable 5G outdoor router built for reliable connectivity in demanding environments. Its IP55-rated housing withstands harsh conditions, and the integrated mounting bracket enables quick, hassle-free installation. Dual SIM and eSIM with automatic switching provide exceptional network flexibility and redundancy. Gigabit Ethernet ports with PoE-in and PoE-out simplify setup by combining power and data in a single cable. Fully RMS-compatible, the OTD500 offers effortless remote management, making it perfect for outdoor connectivity solutions.
Key features
- IP55 - IP55 durability for outdoor deployment
- CONNECTIVITY - 5G, 4G Cat 19, 3G
- eSIM™ - Seamless connectivity with eSIM™ SGP.22
- POE-IN/OUT - 1 x PoE-in and 1 x PoE-out port
Package contents
- OTD500 Router
- Router Holder
- QSG (Quick Start Guide)
- Packaging Box
Свали
Технически параметри
LAN ports
Design
Outdoor
Supported VPN
PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE, Tinc
Power over Ethernet
42 .. 57V DC
Operating mode
Cellular router
Management
Web management, SSH, Teltonika RMS
Wireless frequency
LTE, 3G (GSM), 4G (GSM), 5G (GSM)
Security
128bit AES, 256bit AES
Type of antenna
Built-in
Fixed antennas
4
Internal antennas
4
Antenna gain [dBi]
23
Integrated 4G/LTE radio part
Yes
Power type
PoE
4G/LTE bands support
(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (5) 850 MHz, (28) 700 MHz, (71) 600 MHz, (32) 1500 MHz
5G bands support
(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n75) 1500 MHz, (n76) 1500 MHz, (n77) 3700 MHz, (n78) 3500 MHz
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
2
LAN speed
(2) 10/100/1000Mbps
Max. power consumption [W]
9
Power via connector/terminal
42.5–57V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 55
Weight [g]
385
Width [mm]
110
Height [mm]
235
Depth [mm]
49
CPU
MediaTek, Dual-Core, 880 MHz, MIPS1004Kc
CPU frequency [MHz]
880
SIM slot
Yes
SIM slots quantity
2
IPv6 support
Yes
Default IP address
192.168.1.1
Internal storage [MB]
256
RAM [MB]
256
Default login and password
admin / (preset password, see label/engraving)
