Teltonika RUTM56 Dual 5/4G Modem Router
Нов
Вашата цена с ДДС (20.0%)
1,162.21 лв
Поръчан за склад
Планирана Дата Доставка на Куриер до Вас 07-05-2025
Описание на продукт
Това е автоматичен превод. Оригиналния текст може да видите тукRUTM56 is a dual 4G/5G router designed for critical applications, featuring 1x 5G and 1x 4G modem and 1x WAN port. The device has two SIM slots, supports eSIM, and is compatible with SA and NSA 5G architectures, ensuring high-speed and uninterrupted connectivity. Wi-Fi 5 and 4x Gigabit Ethernet guarantee sufficient performance, while RutOS handles system configuration. RUTM56 is RMS compatible and ideal for secure and efficient remote management.
Key Features
- DUAL MODEM: Ensures continuous operation by providing seamless fallback
- DUAL SIM & eSIM™: Switches to backup connectivity (SIM2) in case of primary connection failure (SIM1)
- SA & NSA: Supports Stand Alone and Non-Stand Alone networks
- COMPATIBILITY: Backward compatible with 3G and 2G networks
Package Contents
- Device
- 14 W power supply
- 6 x 5G mobile antenna (magnetic, SMA male)
- 2 x Wi-Fi antenna (magnetic, RP-SMA male, 1.5 m cable)
- 1 x GNSS antenna (adhesive, SMA male, 3 m cable)
- Ethernet cable (1.5 m)
- SIM adapter kit
- QSG (Quick Start Guide)
Свали
Технически параметри
LAN ports
Design
Industry
Power over Ethernet
9 .. 50V DC
Operating mode
AP Router, Cellular router
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11b/g, 802.11n, airMAX ac
Transmission speed - 2.4GHz [Mb/s]
300
Transmission speed - 5GHz [Mb/s]
866
Security
WEP, WPA, WPA2
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Detachable
Detachable antennas
9
RF connectors
(1) SMA female, (2) RSMA female, (6) SMA female
Antenna gain [dBi]
2, 3
Integrated 4G/LTE radio part
Yes
4G/LTE bands support
(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz
Power type
4-pin automotive
5G bands support
(n1) 2100 MHz, (n20) 800 MHz, (n28) 700 MHz, (n3) 1800 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n75) 1500 MHz, (n76) 1500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n8) 900 MHz, (n71) 600 MHz
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
4
LAN speed
(4) 10/100/1000Mbps
Max. power consumption [W]
12,5
Power via connector/terminal
9 .. 50V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
515
Depth [mm]
95
Width [mm]
132
Height [mm]
44
SIM slots quantity
2
SIM slot
Yes
IPv6 support
Yes
GPS modul
Yes
