Thermally insulated cabinet LC-07 15U 700x400, grey, without ventilation unit
Планирана Дата Доставка на Куриер до Вас 08-10-2025
Описание на продукт
Това е автоматичен превод. Оригиналния текст може да видите тукThe Solarix LC-07 insulated outdoor data cabinet is designed for the installation of structured cabling components, particularly in outdoor environments. The frame of the LC-07 cabinet consists of a welded structure with a solid roof. Mounting holes are provided on the back for wall installation. On the front, the cabinet features solid metal doors equipped with a swing handle, a cylinder lock, and a three-point locking mechanism. The side panels can be opened from the inside and replaced with variants that are either solid or include openings for fan mounting. The cabinet also includes a removable roof cover – a canopy that serves as protection against rain and direct sunlight. For easier handling, the cabinet is equipped with four lifting eyes. Cable entry is provided through cable glands located at the bottom of the cabinet. The standard equipment includes two pairs of sliding 19" vertical rails. The cabinet is fully thermally insulated.
The surface finish is a thermosetting powder coating in RAL 7035 grey (external version) with a layer thickness of 80 to 120 µm. The coating is intended for outdoor use and consists of pure polyester with increased resistance to sunlight and weathering. If the cabinet is to be permanently placed on a fixed base, it should be equipped with a pedestal.
Standard configuration:
- Height: 15U
- Width: 700 mm
- Depth: 400 mm
Construction
- Welded thermally insulated frame
- Front solid metal thermally insulated doors with lever handle, cylinder lock, and three-point locking system
- Doors open 180°, external hinges, option for left or right opening
- Removable side panels, available with or without fan openings
- 12x PG-16 cable glands in the bottom of the cabinet
- 2 pairs of sliding 19" vertical rails
- Roof cover (canopy) with lifting eyes for easier handling
- Load capacity: 100 kg
- IP rating: IP55 – with solid side panels
- IP rating: IP43 – with ventilated side panels
