3G/4G support

Yes

Power over Ethernet

9 .. 50V DC

Wireless frequency

2.4 + 5 GHz (dual band), LTE, 4G (GSM), 5G (GSM)

WiFi standards

802.11n, 802.11ac, 802.11b/g, 802.11ac - wave2

Transmission speed - 2.4GHz [Mb/s]

300

Transmission speed - 5GHz [Mb/s]

866

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

RF connectors

(5) SMA male, (2) RP-SMA

Power type

PoE, DC terminal

4G/LTE bands support

(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (28) 700 MHz

5G bands support

(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n77) 3700 MHz, (n78) 3500 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

5

LAN speed

(4) 10/100/1000Mbps + (1) 10/100/1000Mbps LAN/WAN

Max. power consumption [W]

18

Power via connector/terminal

9 .. 50V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

533

Height [mm]

44

Depth [mm]

95

Width [mm]

132

CPU

ARM Cortex A7

CPU frequency [MHz]

717

SIM slot

Yes

SIM slots quantity

2

USB

Yes

Default IP address

192.168.1.1

Internal storage [MB]

256

RAM [MB]

256

Default login and password

admin / admin01

GPS modul

Yes
