Protection class

IP30

Design

Industry

Wireless frequency

LTE, 3G (GSM)

Type of antenna

Detachable

Detachable antennas

1

RF connectors

(1) SMA female

Integrated 4G/LTE radio part

Yes

Power type

DC terminal

4G/LTE bands support

(1) 2100 MHz, (2) 1900 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (31) 450 MHz, (38) 2600 MHz, (4) 1700 MHz, (40) 2300 MHz, (41) 2500 MHz, (5) 850 MHz, (66) 1700 MHz, (7) 2600 MHz, (8) 900 MHz, (87) 410 MHz, (72) 450 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN speed

(1) 10/100Mbps

LAN ports 100M

1

Max. power consumption [W]

5

Serial port

RS-232, RS-485

Power via connector/terminal

9 .. 57V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

175

Width [mm]

83

Height [mm]

25

Depth [mm]

83

CPU frequency [MHz]

580

SIM slots quantity

2

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

16

RAM [MB]

128

Default login and password

admin / (preset password, see label/engraving)
