Protection class

IP30

Design

Desktop, DIN rail

Supported VPN

PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE

Wireless frequency

3G (GSM), 4G (GSM), 5G (GSM)

RF connectors

(4) SMA female

Power type

DC connector

4G/LTE bands support

(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (28) 700 MHz, (32) 1500 MHz, (71) 600 MHz

5G bands support

(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n8) 900 MHz, (n71) 600 MHz, (n75) 1500 MHz, (n76) 1500 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

1

LAN speed

(1) 100/1000/2500Mbps

Max. power consumption [W]

5

Power via connector/terminal

9 .. 30V DC

Operating temperature [°C]

-40 up to 75

Weight [g]

241

Width [mm]

100

Height [mm]

30

Depth [mm]

93

SIM slot

Yes

SIM slots quantity

1

Internal storage [MB]

512

RAM [MB]

256
