Jumbo frame [Bytes]

9216

Design

DIN rail, On the wall, Industry

Switchning capacity [Gbps]

20

MAC address table

2000

Web management

Yes

Management

Wi-Tek Cloud, Web management

Features

VLAN

Power type

DC connector, DC terminal

Fans

No

LAN ports

8

LAN speed

(8) 10/100/1000Mbps

Max. LAN ports speed

1G

PoE type

PoE-Out (only)

SFP cages

2

Optical interfaces

(2) 1000Mbps

PoE-Out standards

802.3af, 802.3at, 802.3bt

PoE Out ports

8

Redundant power supply

Yes

PoE budget [W]

145

Max. power consumption [W]

5

Chassis design

Metal

Power via connector/terminal

48 .. 57V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

680

Depth [mm]

25

Width [mm]

180

Height [mm]

140

Default IP address

192.168.0.1, Dynamic from DHCP

Default login and password

Is set by the user at the first startup
