F/B ratio [dB]

28

Designed for mast diameter [mm]

40 up to 80

Wind load [km/h]

160

Protection class

IP65

Wireless frequency

5 GHz

Elevation beam width (-6dB) [°]

14

Azimuth beam width (-6dB) [°]

14

Antenna type

Directional

RF connectors

TwistPort

Purpose

Outdoor

Antenna gain [dBi]

21

Material

Aluminum, UV stabilized ABS plastic, Polycarbonate, Stainless steel

Operating temperature [°C]

-40 up to 60

Weight [kg]

2,5

Width [mm]

345

Height [mm]

345

Depth [mm]

263
