WAN speed

(1) 10/100/1000Mbps

Protection class

IP30

Design

Desktop, Industry

Supported VPN

PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE, Tinc

Operating mode

Client, AP Router, Access Point, Cellular router

Management

Web management, SSH, Teltonika RMS

Wireless frequency

2.4 + 5 GHz (dual band), LTE, 3G (GSM), 4G (GSM), 5G (GSM)

WiFi standards

802.11n, 802.11ac, 802.11b/g, 802.11ac - wave2

MU-MIMO

Yes

Transmission speed - 5GHz [Mb/s]

866

Transmission speed - 2.4GHz [Mb/s]

300

Security

WPA, WPA2, WPA3

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

Type of antenna

Detachable

Detachable antennas

7

RF connectors

(2) RSMA female, (5) SMA female

Purpose

Indoor

Integrated 4G/LTE radio part

Yes

Power type

M12 A code 4-pin male connector

4G/LTE bands support

(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (71) 600 MHz

5G bands support

(n1) 2100 MHz, (n3) 1800 MHz, (n7) 2600 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n71) 600 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

3

LAN speed

(3) 10/100/1000Mbps

Max. power consumption [W]

16

Power via connector/terminal

9 .. 50V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

550

Width [mm]

167

Height [mm]

46

Depth [mm]

112

CPU

MIPS1004Kc

CPU frequency [MHz]

880

SIM slot

Yes

SIM slots quantity

2

IPv6 support

Yes

Default IP address

192.168.1.1

Default login and password

admin / (preset password, see label/engraving)

GPS modul

Yes
