Power over Ethernet

16 .. 57V DC

Design

On the wall, Desktop, DIN rail

Supported VPN

PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE, Tinc

Operating mode

Client, AP Router, Access Point, Cellular router

Management

Web management, SSH, Teltonika RMS

Wireless frequency

2.4 + 5 GHz (dual band), LTE, 4G (GSM), 5G (GSM)

WiFi standards

802.11n, 802.11b/g

Transmission speed - 2.4GHz [Mb/s]

300

Security

WPA, WPA2, WPA3

2.4GHz MIMO

1 x 1 SISO

5GHz MIMO

1 x 1 SISO

Type of antenna

Detachable

Detachable antennas

3

RF connectors

(1) RSMA female, (2) SMA female

Integrated 4G/LTE radio part

Yes

Power type

DC connector, PoE

4G/LTE bands support

(1) 2100 MHz, (2) 1900 MHz, (3) 1800 MHz, (4) 1700 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (5) 850 MHz, (12) 700 MHz, (17) 700 MHz, (25) 1900 MHz, (26) 850 MHz, (28) 700 MHz, (66) 1700 MHz, (71) 600 MHz, (13) 700 MHz, (18) 850 MHz, (19) 850 MHz

5G bands support

(n1) 2100 MHz, (n3) 1800 MHz, (n5) 850 MHz, (n7) 2600 MHz, (n8) 900 MHz, (n20) 800 MHz, (n28) 700 MHz, (n38) 2600 MHz, (n40) 2300 MHz, (n41) 2500 MHz, (n77) 3700 MHz, (n78) 3500 MHz, (n79) 4700 MHz, (n66) 1700 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

2

LAN speed

(2) 10/100Mbps (1x LAN/1x WAN)

Max. power consumption [W]

3,5

Power via connector/terminal

9 .. 57V DC

Buttons

Reset

Weight [g]

132

Width [mm]

83

Height [mm]

25

Depth [mm]

83

CPU

Mediatek, 580 Mhz, MIPS 24KEc

CPU frequency [MHz]

580

SIM slot

Yes

SIM slots quantity

2

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

32

RAM [MB]

128

Default login and password

admin / (preset password, see label/engraving)
